IO-Link transceiver is industry’s smallest, most integrated
Housed in a 2.5 x 2.5mm WLP package and designed to save more than 60% of pcb space, Maxim's new IO-Link transceiver is claimed to be the smallest and most integrated in the world.
![](/media/dk2a5dju/maxim-1.jpg?width=1002&height=564&bgcolor=White&v=1d9d7658a2835a0)
The MAX14821 is optimised for point to point communication between industrial controllers and sensor modules and actuators. It supports all specified IO-Link data rates (4.8, 38.4 and 230.4kp/s) and also allows for 24V binary sensor/actuator applications, enabling manufacturers to use it for non IO-Link applications.
The transceiver incorporates a 12MHz SPI interface for control and monitoring and is configurable with numerous alarms and fault detection through its registers. Built in 5 and 3.3V linear regulators are said to provide more design flexibility than the competition's single regulator designs.
For more robust performance in abnormal industrial environments, the device features reverse-voltage protection on the 24V interface lines and short circuit and thermal protection. Under voltage monitoring is provided for all voltage pins, and a slew rate limiter has been implemented to reduce EMI emissions and reflections.
