The new variants have been added to complement the existing symmetrical 2-power/8-signal and 4-power/8-signal layouts.
There are 6 new contact arrangements that feature 2 to 6 power contacts and 4 to 24 signal contacts. These have a non-symmetrical structure, with the power contacts situated at one end and the data contacts at the other. The power contacts have a 10A current rating, and the signal contacts are rated for 2.8A (maximum).
A range of hardware fixings are available for each contact layout. Both male and female connectors can be supplied in either standard gender or reverse fix. There are front and rear panel mount options, plus board-mount fixings to reduce any strain placed on solder joints. In total, 72 extra Gecko-MT connector variants have been added.
As with all the Gecko connectors in Harwin’s HRi product offering, these latest variants have high resilience to shock and vibration, plus compact size and lightweight construction. They support a -65°C to +150°C operating temperature range, and 1,000 (minimum) mating cycle durability. Evaluation samples are available on request.
The company also provides a cable assembly service on all Gecko connectors - supplying ready-made, full inspected harnesses.
