MICROCONTROLLERS: MCU enables intelligent sensing

The PIC16F753 offers all the key features of the PIC12F752, such as the integrated Complementary Output Generator (COG) peripheral that provides non-overlapping, complementary waveforms for inputs such as comparators and Pulse Width Modulation (PWM) peripherals, while enabling dead-band control, auto shutdown, auto reset, phase control and blanking control. Additionally, the PIC16F753 offers an Op Amp with 3 MHz of Gain Bandwidth Product (GBWP), and a slope compensation circuit to help in Switch Mode Power Supply (SMPS) applications. The new MCU also features 3.5 KB of self read-write programme memory, 128B of RAM, an on-chip 10-bit ADC, 9-bit DAC, capture/compare PWM modules, high-performance comparators, and two 50 mA-capable I/Os, enabling engineers to increase overall system capabilities and reduce costs. With increased intelligent analogue capabilities, the PIC16F753 helps to boost system performance and efficiency while reducing system costs, especially for newer LED-lighting and smart-energy applications. With its numerous on-chip general-purpose and specialised peripherals, including the integrated COG, high-performance comparators and 50mA outputs for direct FET drive, the PIC16F753 MCU meets the needs of various applications. The high-voltage version incorporates a shunt regulator that allows operation from 2V to an unspecified user-defined maximum voltage level, with less than 2mA operating current. This high-voltage variant is ideal for cost-sensitive applications with high-voltage power rails. Additionally, the 8-channel, 10-bit ADC can be used to implement various sensors and mTouch sensing applications, including capacitive touch. The PIC16F753 MCU enables efficient power conversion for applications such as LED lighting and power control. It also provides a versatile platform for incorporating intelligence into numerous automotive, consumer, commercial or industrial applications, where it enables a smart system infrastructure with increased efficiencies, reduced costs and an enhanced user experience. Company and product info Microchip Technology Inc. is a leading provider of microcontroller, mixed-signal analog, and Flash-IP solutions, providing low-risk product development, lower total system cost and faster time to market for thousands of diverse customer applications worldwide. Headquartered in Chandler, Arizona, Microchip offers outstanding technical support along with dependable delivery and quality. Product range • Microcontrollers & Digital Signal Controllers • Analogue & Interface Products • Touch & Gesture Sensing Solutions • RF & Wireless Products • Memory Products • Embedded Security Products • Development Systems • USB & Ethernet Solutions Standards and certifications • ISO/TS-16949 • ISO-9001 • ISO 14001 • OHSAS 18001 Industries/sectors served • Industrial • Consumer • Appliance • Automotive • Medical • Automation • Communications Contact info: Microchip Technology 720 Wharfedale Road IQ Winnersh Wokingham Berkshire RG41 5TP T: +44 (0)118 921 5800 E: euro.enquiry@microchip.com W: http://support.microchip.com
